High Temperature 1500C Vacuum Molybdenum Belt Furnace
Features
Controller: Features an intelligent system with 30-segment programmable heating curves.Heating and temperature control accuracy reaches ±1°C.
High-Temperature Molybdenum Strip: Heated by molybdenum strips inside the chamber, ensuring uniform heating, high cleanliness, and excellent process ability.
Tight Fit: Equipped with sensor failure detection, accompanied by audible and visual alarm prompts.
Easy Operation: High degree of automation with a user-friendly human-machine interface for convenient and efficient operation.
Specification
Item | Specification |
Voltage (AC) | 380V |
Temperature Control Accuracy | ±1℃ |
Chamber Size (L×W×H) | 400×200×200 mm 400×350×300 mm 600×400×400 mm 900×600×600 mm |
Working Temperature | Room Temperature ~ 1500℃ |
Max. Temperature | 1500℃ |
Heating Element | High-Temperature Molybdenum Sheets |
Max. Heating Rate | 1-20℃/min (adjustable) |
Atmosphere | Nitrogen (N₂), Argon (Ar), Hydrogen (H₂) and other gases available |
Heating Power | 42 kW / 67 kW / 105 kW / 185 kW |
Insulation Material | Molybdenum + Stainless Steel Sheets |
Vacuum Level | 6.67×10⁻³ Pa (Mechanical Pump + Diffusion Pump) 6.67×10⁻⁴ Pa (Mechanical Pump + Molecular Pump) |
Control System | Fully automatic control system with temperature calibration and compensation functions; 30-segment time-temperature curve programmable |
